io.module

P+E1M00000000
io.module

  • 总体特征

    io.module is the new device developed by Carel for data acquisition and activation of outputs managed by a Carel supervisor or generic Building Management System (BMS). This product supports both the Carel protocol and the Modbus protocol, and features:

    • 4 temperature inputs, configurable as NTC or PT1000;
    • 4 digital inputs
    • 2 active probe inputs, which can be set as 4-20 mA, 0-5 V or 0-10 V.



    The device is equipped with 6 electromechanical relays, which can be controlled by the BMS or associated with alarm logic. The serial communication parameters, including the choice of the protocol used, can be set using the easy-to-access switches on io.module.

  • 更多

    Versatility

    Can be used as an input-output expansion for both Carel and third-party supervisory systems using the standard Modbus protocol.

    Alarms

    • Management of high and low temperature alarms and other values, with optional notification delays;
    • Possibility to create groups of alarms, which can also control the relays for activating external devices.

    Easy configuration

    Wide range of inputs for temperature and generic values, 6 relay outputs, all easily configurable and manageable via Modbus.

    Configurable logic

    Possible associations between probes, digital inputs and relays.

    Higher accuracy

    Possibility to individually calibrate each probe so as to optimise accuracy across the operating range.






文档

技术

  • 2D/3D 图纸
    * Entries are ordered by date
    代码 描述 语言 日期 * 版本
    代码 2d-3d io.module

    		 描述 2D-3D drawings io.module

    		 语言 ALL

    		 日期 27/04/2023

    		 版本 R00

  • 技术说明
    * Entries are ordered by date
    代码 描述 语言 日期 * 版本
    代码 +0500109IE

    		 描述 P+E1M*: io.module modulo Input/Output su RS485 Input/output module on RS485

    		 语言 ENG  ITA

    		 日期 12/04/2024

    		 版本 1.1

    代码 +0500109FR

    		 描述 P+E1M*: io.module - module Entrée/Sortie sur RS485 / Input/output module on RS485

    		 语言 ENG  FRE

    		 日期 12/04/2024

    		 版本 1.1

  • 用户手册
    * Entries are ordered by date
    代码 描述 语言 日期 * 版本
    代码 +0300142IE

    		 描述 io.module Modulo Input/Output su RS485

    		 语言 ENG  ITA

    		 日期 27/06/2024

    		 版本 1.0


产品图片

  • 高清图片
    * Entries are ordered by date
    代码 描述 语言 日期 * 版本
    代码 PH22LPC301-io-module

    		 描述 CAREL - io.module

    		 语言 ALL

    		 日期 29/05/2023

    		 版本 R.0
